Product Description
Manual Hub Conversion- Toyota 4Runner, Pickup Truck & Van Manual Hub Conversion (1986-1988) Kit-1064
This is a OEM Aisin manual locking hub conversion kit with include everything you need to swap your automatic locking hubs to manual locking hubs for 1985-1988 IFS Toyota Pickup Trucks & 4Runner. This also fits 86-89 Toyota Van
Auto Hubs - Some 1984 to 1989 4Runners and 1984 to 1988 Pickups came with Auto Hubs. The Auto Hub has a clutch inside the hub that will lock when it receives forward movement of the axle. The Auto Hubs are less reliable than the Manual Hubs, and will sometimes unlock when the vehicle is in reverse. It is fairly common to swap Auto Hubs to Manual Hubs
Automatic Differential Disconnect (ADD) - Toyota introduced the Automatic Differential Disconnect (ADD) 4-wheel drive system on the Pickup in 1989, and on the 4Runner with the 1990 redesign. This system is composed of a vacuum-activated shift fork in the front differential driver's side axle tube: when the transfer case lever is moved to the 4Hi position, vacuum is applied to the fork which in turn moves a sleeve to lock the inner stub axle shaft from the carrier to another shaft in the tube. This axle assembly powers the driver's side wheel, while the passenger side is a single shaft from the carrier to the inner CV joint. While in 2WD, the driver's side axle is disconnected within the tube. All ADD-equipped Toyotas came with Locked Hubs. To switch to a manual hub you do not need the kit you only need FHT-018 Manual Hub.
Brand- Aisin
Sold As- Pictured
Make | Model | Engine | Years |
Toyota Toyota |
4Runner 4Runner |
2.4L 22R, 22RE 3.0L 3VZ-E V6 |
1986-1995 1986-1995 |
Toyota Toyota |
Pickup Truck Pickup Truck |
2.4L 22R, 22RE 3.0L 3VZ-E V6 |
1986-1995 1986-1995 |
Toyota |
Van |
2.2L 4YEC |
1986-1989 |
Product Videos
Custom Field
Product Reviews
2 Reviews Hide Reviews Show Reviews
-
IFS Hubs
Product was package nicely and everything was there without being damaged. All parts were good quality and exactly what I needed. Definitely would recommend!
-
Free locking hubs
All items advertised arrived in a timely manor. Used to convert vacuum add 4wheel drive to manual locking. Easy to install. I didn’t need all the nuts and washers but ending up using on one side.
